High Precision Shimpo Gearbox Planetary Gear Reducer VRB140 For Robot

Ask Lasest Price
Brand Name :	Nidec
Model Number :	VRB
Certification :	CE,ISO
Price :	Negotiation
Payment Terms :	L/C, T/T
Supply Ability :	100,000 pcs per month
Delivery Time :	Negotiation

Add to Cart

Product Details
Company Profile

High Precision Shimpo Gearbox Planetary Gear Reducer VRB140 For Robot

Product Description:

Nidec Shimpo Gearbox transmissions are high quality gearboxes designed for reliable and efficient operation in robotic, automation equipment, and CNC machine applications. Manufactured by Nidec Shimpo, this gearbox is built with an iron material for maximum radial load of 9100N and a planetary gearing arrangement. Shimpo Gearbox is designed for maximum durability and performance, making it the perfect choice for any automated machinery.

Technical Parameters:

Frame size	Stage	Ratio	Nominal output torque	Maximum output torque	Emergency stop torque	Nominal input speed	Maximum input speed	Permitted radial load	Permitted axial load
Frame size	Stage	Ratio	[Nm]	[Nm]	[Nm]	[rpm]	[rpm]	[N]	[N]
140	1 Single	3	240	470	1000	2000	4000	3200	2400
		4	240	700	1250	2000	4000	3500	2700
		5	360	700	1250	2000	4000	3800	3000
		6	360	700	1250	2000	4000	4000	3300
		7	366	700	1250	2000	4000	4200	3500
		8	360	700	1250	2000	4000	4400	3700
		9	240	470	1000	2000	4000	4600	3900
		10	240	470	1000	2000	4000	4700	4100
	Double	15	240	470	1000	2000	4000	5400	4900
		16	360	700	1250	2000	4000	5500	5000
		20	360	700	1250	2000	4000	6000	5500
		25	360	700	1250	2000	4000	6400	6100
		28	360	700	1250	2000	4000	6700	6400
		30	240	470	1000	2000	4000	6800	6600
		35	360	700	1250	2000	4000	7200	7000
		40	360	700	1250	2000	4000	7500	7500
		45	240	470	1000	2000	4000	7800	7900
		50	360	700	1250	2000	4000	8100	8200
		60	360	700	1250	2000	4000	8600	8200
		70	360	700	1250	2000	4000	9100	8200
		80	360	700	1250	2000	4000	9100	8200
		90	240	470	1000	2000	4000	9100	8200
		100	240	470	1000	2000	4000	9100	8200

Frame size	Stage	Ratio	Maximum radial load	Maximum axial load	Weight	Moment of inertia (≦φ19)	Moment of inertia (≦φ28)	Moment of inertia (≦φ38)	Moment of inertia (≦φ48)
Frame size	Stage	Ratio	[N]	[N]	[kg]	[kgcm2]	[kgcm2]	[kgcm2]	[kgcm2]
140	1 Single	3	9100	8200	16	-	12	20	42
		4	9100	8200		-	7.5	15	37
		5	9100	8200		-	5.8	14	36
		6	9100	8200		-	4.9	13	35
		7	9100	8200		-	4.1	12	34
		8	9100	8200		-	3.8	12	34
		9	9100	8200		-	3.6	11	34
		10	9100	8200		-	3.5	11	34
	Double	15	9100	8200	17	1.3	3.2	11	-
		16	9100	8200		1.5	3.1	11	-
		20	9100	8200		1.2	3.1	11	-
		25	9100	8200		1.1	3.3	11	-
		28	9100	8200		1.4	2.8	11	-
		30	9100	8200		0.85	3.1	10	-
		35	9100	8200		1.1	2.8	11	-
		40	9100	8200		0.83	3.0	10	-
		45	9100	8200		1.1	2.8	11	-
		50	9100	8200		0.81	2.8	10	-
		60	9100	8200		0.81	2.8	10	-
		70	9100	8200		0.80	2.8	10	-
		80	9100	8200		0.80	2.8	10	-
		90	9100	8200		0.80	2.8	10	-
		100	9100	8200		0.80	2.8	10	-

Gear Types:

The Nidec Shimpo gearbox is available in a variety of gear types, including spur gears, helical gears, bevel gears, and worm gears. Each gear type has different advantages and disadvantages, and the choice of gear type will depend on the specific requirements of the application.
