Stainless Steel Nidec Shimpo VRS Series Planetary Gearbox For Industrial

Ask Lasest Price
Brand Name :	Nidec
Model Number :	VRS
Certification :	CE,ISO
Price :	Negotiation
Payment Terms :	L/C, T/T
Supply Ability :	100,000 pcs per month
Delivery Time :	Negotiation

Add to Cart

Product Details
Company Profile

Stainless Steel Nidec Shimpo VRS Series Planetary Gearbox For Industrial

Product Description:

Compact and precise, the VRS is the ideal solution for demanding positioning accuracy and speed requirements. This product is a proven performer in higher speed, continuous duty applications where heat reduction is critical. Equipped with two rows of robust tapered roller bearings, the VRS runs smoothly and quietly even with the most challenging dynamic and static forces.

The VRS is available with reduced backlash, less than 2 arc-min, to handle dynamic machine tool and robotic applications with ease. With maximum acceleration torques up to 3700Nm, this product is an excellent partner to higher capacity servomotor models.

Technical Parameters:

Frame Size	Stage	Ratio	Nominal Output torque	Maximum Output torque	Emergency stop torque	Nominal Input speed	Maximum Input speed	Permitted Radial load	Permitted Axial load
Frame Size	Stage	Ratio	[Nm]	[Nm]	[Nm]	[rpm]	[rpm]	[N]	[N]
075B	1 Single	3	50	80	200	3000	6000	2300	3400
		4	75	125	250	3000	6000	2500	3700
		5	75	125	250	3000	6000	2700	3900
		6	75	125	250	3000	6000	2800	3900
		7	75	125	250	3000	6000	3000	3900
		8	75	125	250	3000	6000	3100	3900
		9	50	80	200	3000	6000	3200	3900
		10	50	80	200	3000	6000	3300	3900
	2 Double	15	50	80	200	3000	6000	3700	3900
		16	75	125	250	3000	6000	3800	3900
		20	75	125	250	3000	6000	4000	3900
		25	75	125	250	3000	6000	4300	3900
		28	75	125	250	3000	6000	4300	3900
		30	50	80	200	3000	6000	4300	3900
		35	75	125	250	3000	6000	4300	3900
		40	75	125	250	3000	6000	4300	3900
		45	50	80	200	3000	6000	4300	3900
		50	75	125	250	3000	6000	4300	3900
		60	75	125	250	3000	6000	4300	3900
		70	75	125	250	3000	6000	4300	3900
		80	75	125	250	3000	6000	4300	3900
		90	50	80	200	3000	6000	4300	3900
		100	50	80	200	3000	6000	4300	3900

Frame Size	Stage	Ratio	Maximum Radial load	Maximum Axial load	Weight	Moment Of inertia ≤8	Moment Of inertia ≤14	Moment Of inertia ≤19	Moment Of inertia ≤28
Frame Size	Stage	Ratio	[N]	[N]	[kg]	[Kgc㎡]	[Kgc㎡]	[Kgc㎡]	[Kgc㎡]
075B	1 Single	3	4300	3900	3.4	-	0.67	1.1	3.1
		4	4300	3900		-	0.47	0.93	2.9
		5	4300	3900		-	0.38	0.85	2.9
		6	4300	3900		-	0.34	0.81	2.8
		7	4300	3900		-	0.31	0.78	2.8
		8	4300	3900		-	0.30	0.76	2.8
		9	4300	3900		-	0.29	0.75	2.8
		10	4300	3900		-	0.29	0.75	2.8
	2 Double	15	4300	3900	3.8	0.13	0.28	0.72	-
		16	4300	3900		0.14	0.30	0.73	-
		20	4300	3900		0.13	0.28	0.72	-
		25	4300	3900		0.12	0.28	0.71	-
		28	4300	3900		0014	0.29	0.73	-
		30	4300	3900		0.099	0.25	0.70	-
		35	4300	3900		0.12	0.27	0.71	-
		40	4300	3900		0.098	0.25	0.69
		45	4300	3900		0.12	0.27	0.71	-
		50	4300	3900		0.098	0.25	0.69	-
		60	4300	3900		0.098	0.25	0.71	-
		70	4300	3900		0.098	0.25	0.69	-
		80	4300	3900		0.097	0.25	0.69	-
		90	4300	3900		0.097	0.25	0.69	-
		100	4300	3900		0.097	0.25	0.69	-

Features:

Housing Coatings and Surface Finishes: FDA White
Epoxy, Steel-It.
Ingress Protection: IP65 Protection available using special input seals, output seals and sealants
Output Shaft Material: Stainless steel, including fasteners
Lubrication: NSF H1 Certified Food Grade Grease
