Planetary Gearbox VRS 075 Nidec Shimpo Gearbox For Industrial Robot Arm

Ask Lasest Price
Brand Name :	Nidec
Model Number :	VRS
Certification :	CE,ISO
Price :	Negotiation
Payment Terms :	L/C, T/T
Supply Ability :	100,000 pcs per month
Delivery Time :	Negotiation

Add to Cart

Product Details
Company Profile

Planetary Gearbox VRS 075 Nidec Shimpo Gearbox For Industrial Robot Arm

Planetary Gearbox Shimpo Nidec VRS 075 Planetary Gearbox For Industrial Robot Arm

Product Description:

Nidec Shimpo Gearbox is a high-reliability, high-quality gearbox transmission made by Nidec Shimpo. It is designed for a wide range of applications, such as robotic, automation equipment, and CNC machines. With a maximum radial load of 3000N and a weight of just 5KG, this gearbox is a great choice for any application. It offers superior performance and reliability in a wide range of industrial settings. The Shimpo Gearbox is designed to provide consistent and reliable operation in the most demanding environments. It is constructed from the highest quality materials and incorporates advanced engineering principles to ensure a long and trouble-free service life. Nidec Shimpo Gearbox is the perfect choice for any application requiring a robust, reliable, and cost-effective gearbox transmission.

Technical Parameters:

Frame Size	Stage	Ratio	Nominal Output torque	Maximum Output torque	Emergency stop torque	Nominal Input speed	Maximum Input speed	Permitted Radial load	Permitted Axial load
Frame Size	Stage	Ratio	[Nm]	[Nm]	[Nm]	[rpm]	[rpm]	[N]	[N]
060B	1 Single	3	50	80	200	3000	6000	2300	3400
		4	75	125	250	3000	6000	2500	3700
		5	75	125	250	3000	6000	2700	3900
		6	75	125	250	3000	6000	2800	3900
		7	75	125	250	3000	6000	3000	3900
		8	75	125	250	3000	6000	3100	3900
		9	50	80	200	3000	6000	3200	3900
		10	50	80	200	3000	6000	3300	3900
	2 Double	15	50	80	200	3000	6000	3700	3900
		16	75	125	250	3000	6000	3800	3900
		20	75	125	250	3000	6000	4000	3900
		25	75	125	250	3000	6000	4300	3900
		28	75	125	250	3000	6000	4300	3900
		30	50	80	200	3000	6000	4300	3900
		35	75	125	250	3000	6000	4300	3900
		40	75	125	250	3000	6000	4300	3900
		45	50	80	200	3000	6000	4300	3900
		50	75	125	250	3000	6000	4300	3900
		60	75	125	250	3000	6000	4300	3900
		70	75	125	250	3000	6000	4300	3900
		80	75	125	250	3000	6000	4300	3900
		90	50	80	200	3000	6000	4300	3900
		100	50	80	200	3000	6000	4300	3900

Frame Size	Stage	Ratio	Maximum Radial load	Maximum Axial load	Weight	Moment Of inertia ≤8	Moment Of inertia ≤14	Moment Of inertia ≤19	Moment Of inertia ≤28
Frame Size	Stage	Ratio	[N]	[N]	[kg]	[Kgc㎡]	[Kgc㎡]	[Kgc㎡]	[Kgc㎡]
060B	1 Single	3	4300	3900	3.4	-	0.67	1.1	3.1
		4	4300	3900		-	0.47	0.93	2.9
		5	4300	3900		-	0.38	0.85	2.9
		6	4300	3900		-	0.34	0.81	2.8
		7	4300	3900		-	0.31	0.78	2.8
		8	4300	3900		-	0.30	0.76	2.8
		9	4300	3900		-	0.29	0.75	2.8
		10	4300	3900		-	0.29	0.75	2.8
	2 Double	15	4300	3900	3.8	0.13	0.28	0.72	-
		16	4300	3900		0.14	0.30	0.73	-
		20	4300	3900		0.13	0.28	0.72	-
		25	4300	3900		0.12	0.28	0.71	-
		28	4300	3900		0.14	0.29	0.73	-
		30	4300	3900		0.099	0.25	0.70	-
		35	4300	3900		0.12	0.27	0.71	-
		40	4300	3900		0.098	0.25	0.69	-
		45	4300	3900		0.12	0.27	0.71	-
		50	4300	3900		0.098	0.25	0.69	-
		60	4300	3900		0.098	0.25	0.69	-
		70	4300	3900		0.097	0.25	0.69	-
		80	4300	3900		0.097	0.25	0.69	-
		90	4300	3900		0.097	0.25	0.69	-
		100	4300	3900		0.097	0.25	0.69	-

Features:

1.Quiet operation
Helical gears contribute to reduce vibration and noise.

2.High precision
Standard backlash is 3 arc-min, ideal for precision control.

3.High rigidity&torque
High rigidity&high torque were achieved by used needle roller bearings.

4.Adapter-bushing connection
Can be attached to any motor all over the world.

5.No Grease leakage
Perfect solution using high viscosity anti-separation grease.

6.Maintenance-free
No need to replace the grease for the life of the unit. Can be attached in any position.
